Pressure Gauge  160mm Bottom Entry  0100 kPa Adjustable Pointer

Floyd H-Duty Pressure Gauge
160mm Dial - Adjustable Pointer
100 kPa (Bottom Connection)

GPH-160B-100P
Price: $440.00
Available

Heavy Duty Stainless Steel Pressure Gauge
160mm Bottom Entry - 0/100 kPa
With Adjustable Secondary Pointer

Stainless Steel Grade 304 Casing
Stainless Steel Grade 316 Wetted Parts
Laminated Safety Glass Window
Glycerine Filled To Reduce Vibration
Dial Diameter 160mm
½" BSPT Connection At Bottom Of Case
0 kPa to 100 kPa Range (Accuracy ±1.6% Of Full Scale)

With Adjustable Secondary Pointer (Red)
Adjustable pointer can be set at any point to indicate desired pressure, maximum pressure or to indicate when filters should be backwashed. Pointer is adjusted using special key provided.

Meets Australian Standard AS1349-1986
Brand: Floyd Australia (PBX Range)

Not Suitable For Use With Oxygen

Suitable for corrosive applications where the medium will not attack stainless steel. Suited to harsh environmental conditions due to the all stainless steel construction. Ideally suited to swimming pool applications where a premium quality pressure gauge is required.
