Heavy Duty Stainless Steel Pressure Gauge
160mm Bottom Entry - 0/1000 kPa
With Adjustable Secondary Pointer
Stainless Steel Grade 304 Casing
Stainless Steel Grade 316 Wetted Parts
Laminated Safety Glass Window
Glycerine Filled To Reduce Vibration
Dial Diameter 160mm
½" BSPT Connection At Bottom Of Case
0 kPa to 1000 kPa Range (Accuracy ±1.6% Of Full Scale)
With Adjustable Secondary Pointer (Red)
Adjustable pointer can be set at any point to indicate desired pressure, maximum pressure or to indicate when filters should be backwashed. Pointer is adjusted using special key provided.
Meets Australian Standard AS1349-1986
Brand: Floyd Australia (PBX Range)
Not Suitable For Use With Oxygen
Suitable for corrosive applications where the medium will not attack stainless steel. Suited to harsh environmental conditions due to the all stainless steel construction. Ideally suited to swimming pool applications where a premium quality pressure gauge is required.
