Pressure Gauge  100mm Rear Entry  0600 kPa Adjustable Pointer

Floyd H-Duty Pressure Gauge
100mm Dial - Adjustable Pointer
600 kPa (Rear Connection)

GPH-100R-600P
Price: $430.00
Available

Heavy Duty Stainless Steel Pressure Gauge
100mm Rear Entry - 0/600 kPa
With Adjustable Secondary Pointer

Stainless Steel Grade 304 Casing
Stainless Steel Grade 316 Wetted Parts
Laminated Safety Glass Window
Glycerine Filled To Reduce Vibration
Dial Diameter 100mm
½" NPT Connection At Rear Of Case
0 kPa to 600 kPa Range (Accuracy ±1.6% Of Full Scale)

With Adjustable Secondary Pointer (Red)
Adjustable pointer can be set at any point to indicate desired pressure, maximum pressure or to indicate when filters should be backwashed. Pointer is adjusted using special key provided.

Meets Australian Standard AS1349-1986
Brand: Floyd Australia (PBX Range)

Not Suitable For Use With Oxygen

Suitable for corrosive applications where the medium will not attack stainless steel. Suited to harsh environmental conditions due to the all stainless steel construction. Ideally suited to swimming pool applications where a premium quality pressure gauge is required.
